Comp Cams Solid Roller Lifters
Endure-XT Solid Roller Lifters: Ford V8 352-428
As the best FE mechanical roller available for performance applications, these Solid Roller Lifters from COMP Cams® are engineered to withstand the demands of aggressive cam lobe designs and increased RPM ranges. They feature a wear resistant tool steel axle, precision sorted needle bearings and EDM Oil InjectionT Technology that guarantees the bearing assembly receives a constant flow of oil. Endure-XT Solid Roller Lifters are heat treated, machined to ultra-high tolerances and fully rebuildable.
- Patented link bar assembly combines the benefits of a removable link bar with the safety of a captured link bar
- EDM Oil InjectionT Technology guarantees that the bearing assembly receives constant, pressurized oil flow via precision hole aimed at the bearings
- Needle bearings are precision sorted by size to evenly distribute loads, which prevents premature wear and failure
- Durable axle is made from wear resistant tool steel to prolong the life of the roller assembly, especially in high RPM applications
SPECIFICATION:
- Diameter: .875?
- Weight: 134g
- Pushrod Seat Location: Centered
-
Oil Hole vs. Axle: Perpendicular
- Seat Height: 2.01?
Vehicle Fitments:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 1963 | Ford | 300 | Base |
| 1958 - 1959 | Ford | Club | Base |
| 1958 - 1971 | Ford | Country Sedan | Base |
| 1958 - 1971 | Ford | Country Squire | Base |
| 1957 - 1958 | Ford | Courier Sedan Delivery | Base |
| 1964 - 1971 | Ford | Custom | Base |
| 1959 - 1960 | Ford | Custom 300 | Base |
| 1964 - 1971 | Ford | Custom 500 | Base |
| 1958 | Ford | Del Rio Wagon | Base |
| 1975 - 1976 | Ford | F-100 | Ranger, Ranger XLT, Custom, Northland, Base |
| 1976 | Ford | F-150 | Base |
| 1975 - 1976 | Ford | F-150 | Northland, Custom, Ranger XLT, Ranger |
| 1965 - 1976 | Ford | F-250 | Base |
| 1975 - 1976 | Ford | F-250 | Custom, Ranger, Northland, Ranger XLT |
| 1975 - 1976 | Ford | F-350 | Base, Custom, Northland, Ranger XLT, Ranger |
| 1959 - 1970 | Ford | Fairlane | 500 |
| 1966 - 1967 | Ford | Fairlane | 500XL |
| 1959 - 1969 | Ford | Fairlane | Base |
| 1959 - 1967 | Ford | Galaxie | Base |
| 1961 | Ford | Galaxie | Club Victoria, Sunliner, Town Victoria, Starliner |
| 1960 | Ford | Galaxie | Special |
| 1962 - 1971 | Ford | Galaxie 500 | Base |
| 1962 - 1964 | Ford | Galaxie 500 | Sunliner, Victoria |
| 1962 - 1970 | Ford | Galaxie 500 | XL |
| 1965 - 1971 | Ford | LTD | Base |
| 1970 - 1971 | Ford | LTD | Brougham |
| 1971 - 1973 | Ford | M-400 | Base |
| 1974 | Ford | M-450 | Base |
| 1969 - 1970 | Ford | Mustang | Boss 302, Boss 429 |
| 1970 | Ford | Mustang | Mach 1, Grande |
| 1967 - 1970 | Ford | Mustang | Shelby GT-500, Shelby GT-350, Base |
| 1968 | Ford | Mustang | Shelby GT-500KR |
| 1958 - 1971 | Ford | Ranch Wagon | Base |
| 1970 | Ford | Ranch Wagon | Police Cruiser |
| 1967 - 1969 | Ford | Ranchero | 500 |
| 1967 | Ford | Ranchero | 500 XL |
| 1957 - 1969 | Ford | Ranchero | Base |
| 1957 - 1958 | Ford | Ranchero | Custom |
| 1968 - 1969 | Ford | Ranchero | GT |
| 1958 - 1959 | Ford | Skyliner | Base |
| 1960 | Ford | Starliner | Base |
| 1958 - 1960 | Ford | Sunliner | Base |
| 1958 - 1968 | Ford | Thunderbird | Base |
| 1969 | Ford | Torino | Cobra, Squire |
| 1968 - 1969 | Ford | Torino | GT, Base |
| 1958 - 1960 | Ford | Victoria | Base |
| 1967 | Mercury | Brougham | Base |
| 1965 - 1967 | Mercury | Caliente | Base |
| 1961 - 1970 | Mercury | Colony Park | Base |
| 1965 | Mercury | Comet | 404, 202 |
| 1965 - 1969 | Mercury | Comet | Base |
| 1961 - 1968 | Mercury | Commuter | Base |
| 1969 - 1970 | Mercury | Cougar | Cobra Jet, Boss 429, Boss 302 |
| 1967 - 1970 | Mercury | Cougar | XR-7, Base |
| 1965 - 1969 | Mercury | Cyclone | Base |
| 1969 | Mercury | Cyclone | Spoiler, CJ |
| 1963 - 1970 | Mercury | Marauder | Base |
| 1969 - 1970 | Mercury | Marauder | X-100 |
| 1967 - 1970 | Mercury | Marquis | Base |
| 1969 - 1970 | Mercury | Marquis | Brougham |
| 1961 | Mercury | Meteor | Base, 600 |
| 1964 - 1968 | Mercury | Montclair | Base |
| 1968 - 1969 | Mercury | Montego | Base, MX |
| 1961 - 1970 | Mercury | Monterey | Base |
| 1962 - 1970 | Mercury | Monterey | Custom |
| 1962 | Mercury | Monterey | Custom S-55 |
| 1963 - 1967 | Mercury | Monterey | S-55 |
| 1964 - 1968 | Mercury | Park Lane | Base |
| 1965 - 1967 | Mercury | Villager | Base |
| 1966 - 1967 | Mercury | Voyager | Base |
