ACL Aluglide Rod Bearing Set Nissan KA24E/KA24DE Size: 0.50

$12.10 Sold out
Shipping calculated at checkout.

ACL Aluglide Rod Bearing Set Nissan KA24E/KA24DE Size: 0.50

Aluglide rod and main bearings were developed for OEM engines and have the inherent physical properties perfectly suited for replacement applications. The proprietary composition is comprised of aluminum, tin and silicon. This metallurgy mix, combined with a steel backing, provides excellent characteristics such as strength, anti-seizure, anti-wear, embeddability and anti-corrosion.

Please measure your engine clearances and order bearing size accordingly to standard shaft size!

* Notes:

  • Price is for 1 COMPLETE SET OF ROD BEARINGS FOR 1 ENGINE. Images may be generic and may not represent actual product.
PART NUMBER 4B2746A
AVAILABLE SIZES

STD, 0.25, 0.50, 0.75, 1.0
OIL CLEARANCE Standard
HALF TYPE Identical Halves
MATERIAL Aluminum, Tin and Silicon
MIN. STD. SHAFT SIZE 1.9670" / 49.961mm
MAX. STD. SHAFT SIZE 1.9675" / 49.974mm
MIN. HOUSING BORE 2.0866" / 53.000mm
MAX. HOUSING BORE 2.0871" / 53.013mm
MAX BEARING THICKNESS 0.0594" / 1.508mm
MAX. OVERALL LENGTH 0.787" / 20.00mm
NOTES Fits KA24E or KA24DE engines


Vehicle Fitments:

Year Make Model Submodel
1991 - 1998 Nissan 240SX LE
1989 - 1998 Nissan 240SX SE, Base
1989 - 1990 Nissan 240SX XE

Products received may vary slightly from images due to manufacturing tolerances or supply chain variables.
